EXCLUSIVE X

TECHNOLOGY
FOR A GREEN LIFESTYLE.

The Beretta R&D laboratories have come up with EXCLUSIVE X, the condensing boiler that marks another step in the evolution of the EXCLUSIVE range whose very name has always signified the top of the brand's wall-hung selection.


The combustion and electronics - the true heart and brain of the boiler - are designed to ensure a product with even higher performance levels and meeting the European environmental sustainability goals.

EXCLUSIVE X is the ideal choice for those wanting something more and looking for green solutions.

SYSTEM
DISPLAY

STAINLESS STEEL
HEAT EXCHANGER

HYBRID
READY

QUICK AND STABLE
HOT WATER

FRONT ACCESS
TO COMPONENTS

QUICK
INSTALLATION

UNIVERSAL
INSTALLATION

EXCLUSIVE
INNOVATION

The stainless steel heat exchanger, the innovative electronics with a hybrid function integrated in the boiler, the lack of external remote controls, and the ability to process blends of natural gas and hydrogen up to 20% give EXCLUSIVE X a highly technological profile, ensuring optimum energy savings which in turn means economic benefits for the user.

EXCLUSIVE
PERFORMANCE

EXCLUSIVE X is the jewel in Beretta's crown. Thanks to the optimised plate heat exchanger, the range can reach DHW performance levels at the top of its category in terms of efficiency, temperature stability and waiting times. The fine-tuned ACC electronic combustion system continually modulates the amount of fuel supplied, ensuring efficiency and first class operation in all conditions and minimising harmful emissions.

EXCLUSIVE
BERETTA

The range sums up Beretta's advanced research, continuing the brand's best style tradition. A continuation that stands out in the product design, echoing the forms of the first Beretta boiler models but with a modern twist, and is also evident in the ease of use and the installation flexibility - two of this brand's distinguishing features that have always been appreciated by the market.

COLOUR
DISPLAY

EXCLUSIVE X has a advanced interface that is the intelligent heart of the boiler's hybrid system


The range is, in fact, HYBRID READY. This means it can directly manage multi-energy systems via the boiler interface, without any external remote control.

The interface, with its elegant covering door with the Beretta logo, is characterised by a backlit LCD colour display that communicates with users and/or installers by means of text and icons.
Display navigation is simple and intuitive thanks to the 4 buttons that lead the user to all the settings and parameter values of the boiler and system.

The innovative profile is completed with advanced self-diagnosis and the EXCLUSIVE X functions that can be activated via the interface.

COLOR BAR

using 4 colours to indicate the boiler operating status and/or any faults

Normal operation
Faults that can be solved by the user
Lockout faults that require the intervention of the Technical Assistance Centre
The system is ready to handle any requests. No operation in progress, or faults detected

A HEART OF STAINLESS STEEL

EXCLUSIVE X is equipped with a primary heat exchanger in stainless steel, with a smooth large-section tube that ensures excellent efficiency and cleanliness over time.

Stainless steel is not only highly resistant to the corrosive action of acid condensate, but also prevents the internal formation of oxides and other electrochemical phenomena often found with installation in old systems.

The single coil geometry (water circuit in series) guarantees a constant flow rate in every section of the heat exchanger, and intrinsically prevents clogging. Front access facilitates the regular cleaning and maintenance of the combustion chamber.

TECHNOLOGY FOR MAXIMUM EFFICIENCY

  • ERP efficiency 94% (*)
  • Low polluting emissions: Class 6 (UNI EN 15502)
  • Modulation up to 1:8
  • 10 L expansion vessel (**)
  • Innovative air filter
  • Electric protection level IPX5D
  • Template supplied
  • Low-consumption modulating circulator (EEI ≤ 0.20), factory set with a 7-metre discharge head bend
  • Semi-automatic system loading
  • Rounded design on models 30 - 35 kw
  • LPG conversion selected with electronic parameter

  • (*) Apart from 25 kW models, with ERP efficiency 93%

    (**) Apart from 25 kW models, with 9-litre expansion vessel

ACTIVE COMBUSTION CONTROL

The ACC system developed by Beretta for EXCLUSIVE X guarantees excellent levels of operation, efficiency and low emissions in all conditions.

Using a flame ionisation current detection sensor, allowing the electronics to continuously vary the amount of fuel injected, the system keeps the air/gas mixture constantly at optimum values across the whole dispensed output modulation field (constant CO2 value).

Thanks to the sophisticated ACC system, combustion is self-regulated to eliminate the need for any calibration and the boiler can work with various gas compositions.

Special attention is paid to CO emissions, with a self-diagnosis function that intervenes on the burner before the legally permitted threshold is exceeded.

EXCLUSIVE X is HYBRID READY

The range was created as a fundamental element of the HYBRID READY selection of products that make up the hybrid technology system conceived and developed in the Beretta research labs.

This system, designed to meet current and future needs to add and control different energy sources (gas/electricity/ renewable), also includes the most innovative energy accumulation and distribution methods.

EXCLUSIVE X was designed with system intelligence integrated in the boiler, REC 10CH, the mind that constantly manages and controls the hybrid system to ensure optimum comfort in an efficient and effective manner at all times.

The Beretta hybrid stands out for its modular approach to the multi-energy world and can evolve over time, adding new components that enhance its overall efficiency.(*)


(*) For the selection of Beretta hybrid system components, refer to the latest update of the Beretta Price List Catalogue and/or contact your local sales agent.

EXCLUSIVE X LOOKS TO THE FUTURE

EXCLUSIVE X was created today, but thinking of the generations of tomorrow.

The new range is already designed to work with blends of natural gas and hydrogen (up to 20%) in line with environmental sustainability goals and the decarbonisation process launched by the European Union.

HYDROGEN IS THE SUSTAINABLE ENERGY SOURCE OF THE FUTURE
  • Available in huge quantities
  • Produced with low-impact, sustainable methods from renewable sources such as wind, photovoltaic and biomass
  • Reduction of emissions
  • A real opportunity for change - to begin the decarbonisation process, fight global climate change and improve the quality of air and life
